Type Tank for oil & chemicals
Flag Malta
Port of registry Valletta
Previous flags United Kingdom
GT 6.785 t
Suez: 7.100 t
Panama: 5.850 t
DWT 9.931 t
NT 3.500 m
Length 126,76 m overall 117,20 m between perpendiculars
Breadth 19,70 m extreme
Draught Summer: 7,74 m
Keel to top of the mast 38,00 m
Depth 9,80 m
Speed Max.: 15,4 knots
Service: 12,7 knots
Built 1999 Keel laid 15.01.1998
Launch date 01.09.1998
Date of completion 20.01.1999
Builder Azimut Benetti Livorno Livorno Italy
Yard number 164
Hull material Steel
Hull type Double hull
Main engine 1x Wartsilä Type 8L38 — 8 cylinder diesel engine — 5.280 kW at 600 rpm
Propellers 1x Controllable pitch propeller
Shaft generator 1x 950 kW
Generators 3x Main diesel generatorsets each 775 kW
Emergency generator 1x
Diesel generatorset 350 kW
Bow thruster 1x 780 bhp / 550 kW
Number of cargo tanks 24
Total capacity 98% 10.893 m³ — whereof 2 deck tanks each 125 m³ Segregations 24 Pumps 22x Deepwell cargo pump each 200 m³/h 2x
Deepwell cargo pump each 100 m³/h
Manifolds Centre manifold to deck: 3,60 m
Centre manifold to stern: 68,76 m
Centre manifold to bow: 58,00 m
Centre manifold to rail: 4,40 m
Tank capacities Fuel oil: 479,5 m³
Diesel oil: 105,5 m³
Lifting equipment 2x
Hose handling cranes — SWL 5,0 t 1x
Hose handling crane — SWL 2,0 t
